熱門關鍵詞： Lumileds2835燈珠飛利浦5050RGBW燈珠飛利浦2835燈珠飛利浦4014燈珠
LUXEON 2835 系列是緊湊型設備，可確保設計自由度及為需要高流明輸出和高效率的項目提供卓越的系統總體解決方案。LUXEON 2835 系列采用行業標準尺寸，是其他 2835 產品和其他常用的中等功率產品的完美升級版本。LUXEON 2835 系列可根據應用要求定制顏色，可為眾多應用提供高效率和高可靠性。該系列有兩種產品可供選擇：輸出較高的 LUXEON 2835C 和輸出較低的 LUXEON 2835E。Product performance at specified test current, Tj=25°C.
|
PRODUCT
|
VOLTAGE
|
NOMINAL CCT
|
MINIMUM CRI
|
LUMINOUS FLUX
(lm) |
TYPICAL LUMINOUS EFFICACY
(lm/W) |
TEST CURRENT
|
PART NUMBER
|
|
|---|---|---|---|---|---|---|---|---|
|
MINIMIM
|
TYPICAL
|
|||||||
| LUXEON 2835E | 9V | 6500K | 70 | 78 | 86 | 158 | 60 | L128-6570EC3500001 |
| 2200K | 80 | 59 | 65 | 119 | 60 | L128-6570EC3500001 | ||
| 2700K | 80 | 67 | 75 | 137 | 60 | L128-2780EC3500001 | ||
| 3000K | 80 | 70 | 78 | 142 | 60 | L128-3080EC3500001 | ||
| 3500K | 80 | 72 | 80 | 147 | 60 | L128-3580EC3500001 | ||
| 4000K | 80 | 74 | 82 | 150 | 60 | L128-4080EC3500001 | ||
| 5000K | 80 | 74 | 82 | 150 | 60 | L128-5080EC3500001 | ||
| 5700K | 80 | 74 | 82 | 150 | 60 | L128-5780EC3500001 | ||
| 6500K | 80 | 74 | 82 | 150 | 60 | L128-6580EC3500001 | ||
| 2200K | 90 | 50 | 55 | 102 | 60 | L128-2290EC3500001 | ||
| 2700K | 90 | 54 | 62 | 114 | 60 | L128-2790EC3500001 | ||
| 3000K | 90 | 57 | 65 | 119 | 60 | L128-3090EC3500001 | ||
| 3500K | 90 | 60 | 68 | 124 | 60 | L128-3590EC3500001 | ||
| 4000K | 90 | 62 | 70 | 128 | 60 | L128-4090EC3500001 | ||
| 5000K | 90 | 62 | 70 | 128 | 60 | L128-5090EC3500001 | ||
| 6V | 2700K | 80 | 45 | 50 | 139 | 60 | L128-2780EB3500001 | |
| 3000K | 80 | 46 | 51 | 142 | 60 | L128-3080EB3500001 | ||
| 3500K | 80 | 46 | 52 | 144 | 60 | L128-3580EB3500001 | ||
| 4000K | 80 | 47 | 54 | 150 | 60 | L128-4080EB3500001 | ||
| 5000K | 80 | 49 | 54 | 150 | 60 | L128-5080EB3500001 | ||
| 5700K | 80 | 49 | 54 | 150 | 60 | L128-5780EB3500001 | ||
| 6500K | 80 | 49 | 54 | 150 | 60 | L128-6580EB3500001 | ||
| 3V | 2700K | 80 | 23 | 25 | 137 | 60 | L128-2780EA3500001 | |
| 3000K | 80 | 24 | 27 | 148 | 60 | L128-3080EA3500001 | ||
| 3500K | 80 | 24 | 28 | 154 | 60 | L128-3580EA3500001 | ||
| 4000K | 80 | 26 | 29 | 159 | 60 | L128-4080EA3500001 | ||
| 5000K | 80 | 26 | 29 | 159 | 60 | L128-5080EA3500001 | ||
| 5700K | 80 | 26 | 29 | 159 | 60 | L128-5780EA3500001 | ||
| 6500K | 80 | 26 | 29 | 159 | 60 | L128-6580EA3500001 | ||
| 2700K | 90 | 19 | 22 | 129 | 60 | L128-2790EA3500001 | ||
| 3000K | 90 | 20 | 22 | 129 | 60 | L128-3090EA3500001 | ||
| 3500K | 90 | 20 | 23 | 135 | 60 | L128-3590EA3500001 | ||
| 4000K | 90 | 21 | 24 | 140 | 60 | L128-4090EA3500001 | ||
| 5000K | 90 | 21 | 24 | 140 | 60 | L128-5090EA3500001 | ||
| 5700K | 90 | 21 | 25 | 146 | 60 | L128-5790EA3500001 | ||
| 6500K | 90 | 21 | 25 | 146 | 60 | L128-6590EA3500001 | ||
| LUXEON 2835C | 6V | 2700K | 80 | 93 | 105 | 141 | 120 | L128-2780CB3500001 |
| 3000K | 80 | 96 | 108 | 145 | 120 | L128-3080CB3500001 | ||
| 3500K | 80 | 99 | 111 | 149 | 120 | L128-3580CB3500001 | ||
| 4000K | 80 | 103 | 115 | 155 | 120 | L128-4080CB3500001 | ||
| 5000K | 80 | 103 | 115 | 155 | 120 | L128-5080CB3500001 | ||
| 5700K | 80 | 103 | 115 | 155 | 120 | L128-5780CB3500001 | ||
| 6500K | 80 | 103 | 115 | 155 | 120 | L128-6580CB3500001 | ||
| 2700K | 90 | 78 | 88 | 120 | 120 | L128-2790CB3500001 | ||
| 3000K | 90 | 81 | 91 | 124 | 120 | L128-3090CB3500001 | ||
| 3500K | 90 | 83 | 93 | 127 | 120 | L128-3590CB3500001 | ||
| 4000K | 90 | 87 | 97 | 133 | 120 | L128-4090CB3500001 | ||
| 5000K | 90 | 87 | 97 | 133 | 120 | L128-5090CB3500001 | ||
| 3V | 2700K | 80 | 49 | 54 | 154 | 120 | L128-2780CA3500001 | |
| 3000K | 80 | 51 | 56 | 160 | 120 | L128-3080CA3500001 | ||
| 3500K | 80 | 53 | 57 | 164 | 120 | L128-3580CA3500001 | ||
| 4000K | 80 | 55 | 60 | 168 | 120 | L128-4080CA3500001 | ||
| 5000K | 80 | 55 | 60 | 168 | 120 | L128-5080CA3500001 | ||
| 5700K | 80 | 55 | 60 | 168 | 120 | L128-5780CA3500001 | ||
| 6500K | 80 | 55 | 60 | 168 | 120 | L128-6580CA3500001 | ||
| 2700K | 90 | 42 | 47 | 132 | 120 | L128-2790CA3500001 | ||
| 3000K | 90 | 42 | 48 | 134 | 120 | L128-3090CA3500001 | ||
| 3500K | 90 | 44 | 50 | 139 | 120 | L128-3590CA3500001 | ||
| 4000K | 90 | 46 | 51 | 143 | 120 | L128-4090CA3500001 | ||
| 5000K | 90 | 46 | 51 | 143 | 120 | L128-5090CA3500001 | ||
| 5700K | 90 | 46 | 52 | 145 | 120 | L128-5790CA3500001 | ||
| 6500K | 90 | 46 | 52 | 145 | 120 | L128-6590CA3500001 | ||
| 3V TVS | 2700K | 80 | 48 | 54 | 149 | 120 | L128-2780CA35000T1 | |
| 3000K | 80 | 50 | 56 | 154 | 120 | L128-3080CA35000T1 | ||
| 3500K | 80 | 52 | 57 | 158 | 120 | L128-3580CA35000T1 | ||
| 4000K | 80 | 54 | 58 | 163 | 120 | L128-4080CA35000T1 | ||
| 5000K | 80 | 54 | 58 | 163 | 120 | L128-5080CA35000T1 | ||
| 5700K | 80 | 54 | 58 | 163 | 120 | L128-5780CA35000T1 | ||
| 6500K | 80 | 54 | 58 | 163 | 120 | L128-6580CA35000T1 | ||
